Multi-Purpose Digital Creasing Machine and Paper Perforating and Paper Slitting Machine Jumbo Paper Roll Slitter Rewinder Machine Paper Converting Machine

Basic Info

Model NO.	FHQB-1600
Packaging	Film
Classification	Roll Paper Cutting Machine
Applicable Process	Process Materials
Suitable Substrates	Paper
Packaging Material	Plastic
Width of Raw Material	1600mm
Suitable Material	Paper, Kraft Paper, Adhesive Sticker Label, etc
Main Motor	4 Kw
Total Power	17 Kw
Error Correction Accuracy	±0.5 mm
Transport Package	Export Wooden Case
Specification	CE
Trademark	Newsun
Origin	China
HS Code	8477800000
Production Capacity	50sets/Month

Product Description

FHQB-1600 Multi-Purpose Digital Creasing Machine and Paper Perforating Machine and Paper Slitting Machine
Main Technical Parameters

Model	FHQB-1600
Width of raw material	1600 mm
Suitable material	Paper, Kraft paper, adhesive sticker label, etc
Max. Diameter of unwinding	Φ1000 mm
Unwinding paper core diameter	3"
Max. Diameter of rewinding	Φ1000 mm
Rewinding paper core diameter	3"
Machine speed	30-300 m/min
Slitting and rewinding width	30-1300 mm
Main motor	4 kw
Rewinding motor	5.5 kw (2 pcs)
Error correction accuracy	±0.5 mm
Weight of machine	4000 kg
Total power	17 kw
Overall dimensions(L×W×H)	3800×3200×1900mm

Electrical and Electronic Components

PLC	SEIMENS
Inverter	YASKAWA, JAPAN
Touch screen	WEINVIEW, TAIWAN
EPC	BIANFU
Magnetic power brake	NINGXIA
Main motor	SEIMENS
Rewinder motor	SEIMENS
Main pneumatic part	JINHUA KAOGEER
Main Bearing	CANADA
Low-voltage apparatus	GERMANY

FEATURE

1. The rewinding shaft working by inverter motor directly. It use vector frequency inverter to realizeautomatic tension control. 2. Rewinding air shaft can discharge, it is convenient for unloading.3. Unwind unit use air brake, roll diameter accounted automatically by PLC, automatic tension control.4. Unwind frame automatic lifting up and down, so it is convenient to load and unload material with high efficiency.5. Slitting unit adopts round knife for slitting, disk tidy, have edge waste device.6. The system has meter counting, automatic stop by setting length you need.7. The system has perfect mechanic, electric and pneumatic design, also good safety protection.
Note:
1. Max. raw paper width 1600mm. Thickness 30-80gsm.2. Max. unwind & rewind diameter:φ1000mm3. Max. slitting speed 300 m/min

USE
This machine is used to slit all kinds of roll materials such as Label, paper.

Specification

1. Unwind unit(1). Unwinding form: 3 inch air shaft.(2). Unwinding rack automatic lifting(3). Unwind controlled by air brake.(4). Maximum diameter of unwind: Φ1000 mm(5). Automatic tension controlled by PLC program.(6). Edge position correction accuracy ≤0.5 mm. (7). Alarm dia for the unwinder.
2. Traction unit (1). AC drive motor for tracking. (2). Synchronous belt drive. (3). Turn the body are made of imported bearings NSK from Japan. (4). Double-roll rollers, combined with soft steel.
3. Slitting unit (1). Slitting adopts round knife for slitting, disk tidy(2). Have edge waste fan blowing device.
4. Rewinding unit (1). Double air shaft up and down rewinding. (2). Rewinder shaft can be discharge.(3). Double variable inverter motor controlled for rewind unit.
